Precision Welded Tubing and Tubing Assemblies in Aerospace & Defense
March 26, 2021

Precision Welded Tubing and Tubing Assemblies in Aerospace & Defense

Precision Welded Tubing and Tubing Assemblies

Bellows Systems manufactures precision welded tubing and tubing assemblies for aerospace ducting, Rocket and Missile Components.

Our aerospace qualified welding processes include,

  • AWS D17.1, Specification For Fusion Welding Of Aerospace Applications.
  • AWS D17.2, Specification For Resistance Welding For Aerospace Applications.
  • AMS 2685, Welding, Tungsten Arc, Inert Gas (GTAW Method).
  • Numerous other current and legacy MIL standards
  • Aerospace and Defense customer specifications.
  • How can we help with your precision welded tubing
Enquire Now
Read More
Alpha Mahatvaraj0 commentMarch 26, 2021Aerospace and Defense
A complete lineup of Piping Expansion Joints and Piping Bellows by Bellows Systems Inc
March 26, 2021

A complete lineup of Piping Expansion Joints and Piping Bellows by Bellows Systems Inc

Piping engineers are continuously faced with problems involving thermal movement, instability, limiting forces on equipment, and absorption of vibrations. The piping design must balance the economics of pipe loops and offsets, space, and fabrication against the cost of expansion joints.

Bellows Systems has made piping engineers lives easier by providing cost-effective, engineered bellows and expansion joint solutions for their piping designs. Its Kopperman Division established in 1894 is one of the oldest manufacturers of expansion joints.

Piping bellows and expansion joints may be used to absorb direct axial expansion or contraction, to absorb equipment vibration, to provide limitation of forces applied to critical equipment and to improve line stability through reduction and control of loads on pipelines.

We offer a complete lineup of piping expansion joint design options and standard sizes ranging from as small as 1” to 48” pipe OD. We can fabricate bellows from single-ply wall thickness of 0.004” to 0.072” and multi-ply designs with up to 6 layers for different pressure classes and vibration loading. Our high-pressure expansion joints can optionally be constructed with root reinforced bellows designs with integral root rings or equalizing rings

Enquire Now
Read More
Alpha Mahatvaraj0 commentMarch 26, 2021Piping Bellows
Dual Bellows type universal expansion joints
March 9, 2021

Dual Bellows type universal expansion joints


Two different dual bellows type universal expansion joints,

  • 36” ID x 41” long with flanges for a compressor station in Texas, CAT GCM – 34 Exhaust.
  • 41” ID x 26” long with weld ends for a refinery in South America.

Dual universal expansion joints are the simplest type of universal expansion joint. They are typically used in low-pressure applications, such as exhaust ducting. They can absorb both axial and lateral movement in the piping.

Enquire Now
Read More
Alpha Mahatvaraj0 commentMarch 9, 2021Expansion Joints, Universal Expansion Joints
Dual Expansion joints
February 18, 2021

Exhaust Bellows : Dual Expansion Joint for 825 SGTB Superior Engine

18” Dual Expansion Joint for a 16 cylinder White Superior 825 SGTB Engine

Bellows Systems has been manufacturing exhaust manifolds and exhaust bellows and expansion joints for Cooper-White Superior engines for over 40 years. Our exhaust manifold products cover the entire range of superior engines and include both,

  • Water jacketed (Wet) Manifolds
  • Insulated (Dry) Manifolds
    21-0065 18inch * 26inch Dual Expansion joints for Whitesuperior Engine Exhaust.

    Our products with robust design have been in maintenance-free service for over two decades. As an example, the wet manifold designs for G825 series engines incorporate 4 ply nickel alloy bellows with liners on the inner jacket. This ensures the expansion joints last the life of the manifold.

    Please visit our product pages for more details

    1. Exhaust Manifolds for Superior Engines
    2. Exhaust Bellows and Expansion Joints for Superior Engines
    Read More
    Alpha Mahatvaraj0 commentFebruary 18, 2021Exhaust Manifolds, Exhaust Systems, Expansion Joints
    January 27, 2021

    What are Multi Ply Metal Bellows and where are they used?

    Multi-ply bellows are made up of a multiple telescoping tube (or plys) of sheet metal. The telescoping tubes are formed (Expanded mandrel or hydraulic) together to form each convolution.

    Multi ply Layer in the Metal bellow
    Why are they better than single-ply bellows?
    • They offer redundance in the event of inner ply failure.
    • The offer much lower stiffness.
    • Leak detection measures can be incorporated to detect ply failure hence providing time to change out the existing expansion joint.
    • Much higher cycle life per corrugation.
    • Corrugated length can be much shorter to achieve similar movement and cycle life performance to that of a single ply bellows.
    What are the drawbacks?
    • They have higher meridional bending stress.
    • They have less resilience to corrosion due to the individual wall thickness.
    • Higher ply count can result in slightly higher manufacturing cost.
    • Increased in-plane and column instability compared to a similar single ply construction.
    • Difficult to repair in the field due to the much thinner ply thickness.
    Read More
    Alpha Mahatvaraj0 commentJanuary 27, 2021Metal Bellows
    High Temperature piping Expansion Joints
    December 11, 2020

    Hinged and Gimbaled piping Expansion Joints for a Natural Gas Fired Heater

    High-Pressure High-Temperature piping Expansion Joints for a Natural Fired Heater at a US AFB.

    • Design pressure of 1,300 Psi and design temperature of 1,250 F.

    • Hydrotest at 1,900 Psi

    Bellows Systems designed and manufactured one hinged and two gimbal expansion joints for a recent project. The gimbal type expansion joints included one with an external cover and removable insulation.
    The bellows materials included Inconel 718 alloy construction with integral root rings and collars. Hinge and Gimbal structural components included 304 SS and 347H SS.

    Hinged bellows were designed to be capable of 7 degrees of angular rotation at design temperature and pressure.

    Bellows Systems is your go-to source for the standard to the most challenging bellows and expansion joint applications.

    Read More
    Alpha Mahatvaraj0 commentDecember 11, 2020Expansion Joints, Oil and Gas
    High Pressure Universal Tied Expansion Joint
    October 15, 2020

    High Pressure Universal Tied Expansion Joint

    Bellows Systems shipped another High Pressure Universal Tied Expansion Joint for a process plant piping application. The Expansion Joint had full Stainless Steel 316/ 316L construction & was designed per EJMA 10th Edition & ASME B31.3.

    Our expansion joints are used in both the pulp line and chemical recovery process. Check our expansion joints for our complete line up of products or chat with one of our experienced sales and engineering staff to find the right solution for you.

    Read More
    Alpha Mahatvaraj0 commentOctober 15, 2020Expansion Joints
    Exhaust compensator for a LPG Tanker
    October 8, 2020

    Exhaust compensator for a LPG Tanker

    Recently we received an urgent request for replacement of the main engine (MAN B&W 8S35MC) exhaust compensator (bellows expansion joint) for a LPG Tanker en-route to Houston. Bellows Systems designed, fabricated and delivered the replacement 4-ply exhaust expansion joint within 5 days. Drop-off and pick-up was successfully completed during the vessel’s Houston port call.

    We also provide quick turn around repair services on exhaust bellows and expansion joints to vessels calling into port of Houston or Galveston.

    Make Bellows Systems your go to source for emergency repairs or rebuilds of exhaust bellows and expansion joints. Call us today to find more about our repair services.

    Read More
    Alpha Mahatvaraj0 commentOctober 8, 2020Expansion Joints
